Assessing the risk of designing a capacitor waveform recorder system using the fMEA method in order to reduce costs

Document Type : Original Article

Authors
Karim Kenarkoohi 1
Mostafa Tamtaji 2
1 Kenarkoohi, Karim, Malek Ashtar University of Technology Physics Department Assistant Professor, Tehran, Iran
2 Assistant Professor of Service Management and Technology Development Department of Allameh Tabatabai University
10.22034/asas.2023.370740.1018
Abstract
The purpose of this research is to evaluate the design risk of the capacitive waveform recorder and extract the critical levels to prevent its occurrence in the waveform recorder. The simulated outputs were extracted using Proteus software in order to select the circuit with appropriate accuracy.
In this research, FMEA method is used to evaluate failure modes. All parts of the waveform recorder were evaluated and states, effects and causes of failure were calculated and evaluated. Then the risk number of each failure was calculated and its crisis level was prioritized.
The purpose of FMEA is to support decisions that reduce the probability of failures and their effects and help improve outputs.
FMEA documents can only include a brief statement of proposed exposures or design changes: replacing elements with more reliable one, introducing backup systems, and new or improved methods that limit damage.
In conducting the research, the general process for FMEA evaluation was determined. Then, by interviewing experts in the field, the failure modes of the design of the capacitor waveform recorder were analyzed. Critical situations were extracted and countermeasures were suggested to improve performance. Two methods of simulation and interview were considered to collect information. The relationship between circuit design cost and design error analysis was extracted and it was observed that with the increase of DFMEA, in addition to increasing the number of parts and increasing the risk of failure, the cost of circuit design and construction and measurement error increases.
Keywords
Design risk
capacitive waveform recorder
critical levels
risk number
error analysis
Subjects
1. Design of Lc Meter Using Arduino. Patil, Sanket Sanjay. 1, s.l. : Journal of Instrumentation and Innovation Sciences, 2019, Vol. 4.
2. Design about Simple Tester of Low Capacitance Based on MAX038. Liping, Zheng. s.l. : Information Technology and Mechatronics Engineering Conference, 2015.
3. Kung, Joseph T. A DIGITAL TECHNIQUE FOR PRECISE MEASUREMENT OF CAPACITOR DIFFERENCES, WITH APPLICATION TO CAPACITIVE INTEGRATED SENSORS. s.l. : Department of Electrical Engineering and Computer Science, 1987.
4. A LOW COST ANALOG LOCK-IN AMPLIFIER FOR CAPACITANCE MEASUREMENTS. Rajan.E, Raja and Suhasini, S. 3, s.l. : International Journal of Advanced Technology in Engineering and Science, 2015, Vol. 3.
5. Risk assessment and analysis in the investigation of accidents in the Saadat Abad electricity district using JHA and FMEA methods. Sima, Ghayib Lu, etc. Tehran: 19th International Electricity Conference, 2004.
6. Numerical Evaluation of Complex Capacitance Measurement Using Pulse Excitation in Electrical Capacitance Tomography. Wanta, Damian, et al. 1864, s.l. : MDPI Electronics, 2022, Vol. 11.
7. Anderson, Robert Alexander . Charge Transfer Capacitance Meter Development For Capacitive Level Sensor. s.l. : MURDOCH UNIVERSITY, 2013.
8. Risk Factors Assessment in Educational Equipment Manufacturers Company Using FMEA. Mirmohammadi, Seyed taghi, Naseripouya, Zahra and Hosseinalipour, Zahra . 2, s.l. : Journal of Health Research in Community, 2016, Vol. 2.
9. LOW VALUE CAPACITANCE MEASUREMENT SYSTEM FOR THE APPLICATION OF MONITORING HUMAN BODY. Arshad, Atika , et al. 1, s.l. : ARPN Journal of Engineering and Applied Sciences, 2016, Vol. 11.
10. Standards for Low Values of Direct Capacitance. Moon, Charles and Sparks, Matilda . s.l. : Journal of Research, 1948, Vol. 41.
11. Low Value Capacitance Measurements for Capacitive Sensors – A Review. RAMANATHAN, Prabhu , et al. ÷, s.l. : Sensors & Transducers, 2013, Vol. 148.
12. Cadwallader, L C. Reliability estimates for selected sensors in fusion applications. s.l. : Idaho National Engineering Laboratory Nuclear Engineering Technologies Department, 1996.
13. METHODS OF ACCURATELY MEASURING CAPACITIVE RH SENSORS. Bull, Kevin . s.l. : 5th International Symposium on Humidity and Moisture, 2006.
14. Potential Failure Mode and Effect Analisis. s.l. : Chrysler Corporation and Ford Company and General Motors Corporation, 2003.
15. Bosch, Robert . Failure Mode and Effects Analysis FMEA. s.l. : SOCOS, 2020.
16. Linkages, Robustness . Failure Mode and Effects Analysis. s.l. : FORD MOTOR COMPANY, 2011.
17. ISO 31000 Risk management. 2018.
Advances in the Standards & Applied Sciences
Volume 1, Issue 2
Winter 2023
Pages 3-9
